MHD5 Spares Parts – Interchangeable with HLX5 Drifter

SL Ref. Part no. Mindrill Part No. Part Name Qty
1.01 550 056 39 5123 210 001 20 Frame 1
1.02 881 140 79 5123 213 055 Plug 12
1.03 865 683 09 5123 206 045 Plug 2
1 .04 550 093 63 5123 210 003 25 Plug 2
$1.05 152 745 38 5123 210 001 21 Cover, Front (- Incl. Parts 1.06) 1
$1.06 152 744 08 5123 210 001 21 10 Bearing Bushing 1
$1.07 152 747 98 5123 210 001 22 Bushing, Shank (- Incl. Parts 1.08) 1
$1.08 152 697 08 5123 210 001 22 10 Bushing 1
$* 1.09 150 809 18 5123 210 001 23 Plate, Gasket 1
* 1.10 300 637 10 5123 210 001 24 O-Ring 1
* 1.1 1 152 748 18 5123 210 001 25 Plate, Gasket 1
$* 1.12 872 189 39 5123 210 001 26 Seal, U 5
$1.13 442 218 50 5123 210 001 27 Hexagon Head Screw 4
$ # 1 .14 850 68749 5123 206 031 Washer, Lock, Double 15
1.15 152 473 28 5123 210 001 29 Seal Housing 1
$* 1.16 550 668 36 5123 210 001 29 10 Piston Rod Guide Ring 2
$1 .17 550 056 76 5123 210 001 30 Adapter Assembly 1
$1.18 812 949 59 5123 210 001 30 10 Lock Nut 1
$*1.19 800 348 19 5123 210 001 30 20 Bonded Seal 1
$* 1.20 800 816 79 5123 210 001 31 O-Ring 1
2 550466 28 5123 210 002 Gearbox 1
@#2 01 152 711 08 5123 210 00220 Bearing Bushing 1
@ 2.02 550 356 04 5123 210 002 21 Bearing Bushing 1
2.03 551 71441 5123 210 002 22 Bearing Assembly (- Incl. Parts 2.04) 1
# 2.04 551 70648 5123 210 00222 10 Bearing Bushing 1
* 2.05 522 10740 5123 210 002 24 O-Ring 1
# 2.06 550 036 03 5123210 002 25 Screw 1
* 2.07 801 802 69 5123 210 002 26 Bonded Seal 1
2.08 871 692 89 5123 213 024 36 Plug 5
@ 3 550 577 98 5123 210 008 Bushing, Rotation 1
#4 152 723 68 5123 210 008 20 Drill Sleeve 1
@ 5 550 508 28 5123 210 009 Driver (Bronze) 1
6 154 194 08 5123 210 016 Gear Wheel 1
@ 7 154 21748 5123 210 017 Shaft, Rotating 1
8 550 007 62 5123 210 018 Housing Assembly 1
# 9 888 09749 5123 210 01821 Needle Bearing 1
# 10 150 797 18 5123 210 019 Side Plate 2
1 1 152 716 38 5123 210 020 Bolt, Special 6
12 152 525 68 5123 210 021 Cap Nut 6
13 550 034 00 5123 210 023 Screw 4
14 887 946 09 5123 210 026 Seal, Shaft 1
# 15 511 108 30 5123 210 027 Bearing, Ball, Deep Groove 1
16 800 658 09 5123 210 042 O-Ring 9
17 853 575 89 5123 210 044 O-Ring 1
18 047 689 68 5123 210 046 Guard 1
19 280 678 90 5123 210 047 Clamp 1
20 550 103 31 5123 210 003 Frame Assembly 1
20.01 150 221 58 5123 210 003 21 Plug 2
* 20.02 522 067 70 5123 210 003 22 O-Ring 2
20.03 882 322 79 5123 210 003 24 Spring-Type Straight Pin 1
20.04 881 139 09 5123 210 003 27 Plu 10
20.05 152 538 58 5123 210 003 28 Plate 1
* 20.06 152 539 88 5123 213 020 Gasket Plate 1
* 20.07 818 735 39 5123 210 003 30 O-Ring 1
# 20.08 800 537 39 5123 206 030 Hexagon Head Screw 3
20.09 881 141 09 5123 210 003 33 Plug 6
20.1 817 094 69 5123 210 003 34 Straight Thread Adapter 1
20.11 816 768 29 5123 210 003 35 Straight Thread Adapter 2
20.12 817 097 49 5123 210 003 36 Plug 1
20.13 816 909 59 5123 210 049 Plug 4
21 550 036 25 5123 210 004 Accumulator 1
21.01 092 602 98 5123 210 004 20 Bladder 2
# 21.02 807 590 69 5123 210 004 21 Valve 2
* 21.03 869 733 29 5123 210 004 21 10 O-Ring 2
21.04 851 682 19 5123 210 004 21 20 Protecting Cap 2
* 21.05 522 134 90 5123 210 004 22 O-Ring 2
* 21.06 819 532 09 5123 210 004 23 O-Ring 2
21.07 151 548 58 5123 210 004 24 Tag 2
21.08 085 370 18 5123 210 004 25 Protecting Cap 2
22 550 036 27 5123 210 005 Accumulator 1
23 152 715 08 5123 210 010 Bearing 1
24 551 991 40 5123 210 011 Rock Dili Piston 1
25 550 047 84 5123 210 012 Cylinder 1
26 152 576 38 5123 210 013 Distributor 1
27 550 023 18 5123 210 014 Bushing 1
28 550 026 37 5123 210 015 Cover 1
29 550 097 85 5123 210 022 Motor Assembly, Hydraulic 1
29.01 150 800 78 5123 210 022 20 Thrust 1
# 29.02 550 065 90 5123 210 022 21 Stud 4
# 29.03 851 068 09 5123 210 038 Double Lock Washer 4
# 29.04 811 260 29 5123 210 022 22 Lock Nut 4
* 29.05 855 207 09 5123 210 022 23 O-Ring 1
* 29.06 855 206 89 5123 206 018 O-Ring 1
* 29.07 814 872 89 5123 210 022 24 O-Ring 1
* 29.08 550 091 04 5123 210 022 25 O-Ring 2
* 29.09 550 351 48 5123 210 022 26 Spring Washer 1
* 30 887 944 59 5123 210 024 Seal, Rod 2
* 31 887 945 89 5123 210 025 Seal, Rod 2
* 32 550 042 26 5123 210 028 Plate, Gasket 2
33 802 198 29 5123 210 029 Hexagon Head Bolt 8
* 34 550 046 25 5123 210 036 Gasket 1
# 35 800 470 59 5123 210 037 Hexagon Head Screw 4
36 851 068 09 5123 210 038 Washer, Lock, Double 4
37 550 152 17 5123 210 040 O-Ring 1
38 801 368 49 5123 210 041 O-Ring 2
39 550 091 05 5123 210 043 O-Ring 2
40 808 788 39 5123 210 045 O-Ring 3
* 41 816 770 19 5123 210 048 Straight Thread Adapter 2
* 42 550 252 93 5123 210 050 Seal Kit 1
43 7804 7585 01 5141 102 3438 70 Shank Adapter 1
BG 005 501 98 5113 210 000 80 Kit Rotation MHD5
BG 008 008 65 5113 210 000 81 Service Kit, Flushing Head MHD5
BG 005495 19 5113 210 000 82 Service Kit, Endurance Kit MHD5
