SN Reference Part No. Mindrill Part No. Description Qty.
1 5141 102 3439 40 Shank Adapter 1
5 3115 2231 00 5201 3115 2231 00 Drill Collar 1
@ 010 3115 0286 00 5201 3115 0286 00 Dome Nut 6
@ 011 3115 0287 00 5201 3115 0287 00 Washer 6
20 3115 3473 83 5201 3115 3473 83 Hydraulic Motor 1
21 3115 0277 00 5201 3115 0277 00 Coupling 1
@ 022 0335 2130 00 5201 0335 2130 00 Circlip 1
# 024 3115 0327 00 5201 3115 0327 00 Gasket 1
@ 025 3115 3548 00 5201 3115 3548 00 Nut 4
@ 050 3115 3164 00 5201 3115 3164 00 Label 1
70 3176 6512 00 5201 3176 6512 00 Nipple 2
71 3176 6514 00 5201 3176 6514 00 Nipple 1
Not Shown 0686 9250 26 5201 0686 9250 26 Plug 2
Not Shown 0686 9250 27 5201 0686 9250 27 Plug 2
30 3115 3451 81 5201 3115 3451 81 Accumulator (Intake) 1
30.1 3115 3451 81-20 5201 3115 3451 81-20 Diaphragm Cover (Intake) 1
30.2 3115 2697 00 5201 3115 2697 00 Diaphragm Housing 1
@ 30.3 3115 1822 01 5201 3115 1822 01 Diaphragm 1
@ 30.4 3115 3768 00 5201 3115 3768 00 Valve 1
@ 30.10 3115 2702 10 5201 3115 2702 10 Screw 2
* 30.12 0663 9056 00 5201 0663 9056 00 O-Ring (For kit) 2
* 30.13 0663 6121 00 5201 0663 6121 00 O-Ring (For kit) 1
* 30.14 0663 2110 00 5201 0663 2110 00 O-Ring (For kit) 1
31 3115 3511 81 5201 3115 3511 81 Accumulator (Damper)
31.1 3115 3511 81 20 5201 3115 3511 81 20 Diaphragm Cover (Damper) 1
31.2 3115 2697 00 5201 3115 2697 00 Diaphragm Housing 1
@ 31.3 3115 1822 01 5201 3115 1822 01 Diaphragm 1
@ 31.4 3115 3768 00 5201 3115 3768 00 Valve 2
@ 31.10 3115 2702 10 5201 3115 2702 10 Screw 2
* 31.12 0663 9056 00 5201 0663 9056 00 O-Ring(For kit) 2
* 31.13 0663 6121 00 5201 0663 6121 00 O-Ring (For kit) 1
* 31.14 0663 2110 00 5201 0663 2110 00 O-Ring(For kit) 1
35.1 0147 1483 03 5201 0147 1483 03 Screw, Hex Hend 1
35.2 3115 2615 20 5201 3115 2615 20 Tube 1
35.3 3115 2885 00 5201 3115 2885 00 Tube Cover 1
35.4 3115 2886 00 5201 3115 2886 00 Pipe 1
35.5 3115 2889 00 5201 3115 2889 00 Pressure Screw 1
*& #35.6 0663 2109 37 5201 0663 2109 37 O-Ring 2
* 35.7 0663 2129 01 5201 0663 2129 01 O-Ring 1
35.8 3115 2618 00 5201 3115 2618 00 End Piece 1
*& #35.9 0663 2128 00 5201 0663 2128 00 O-Ring 2
@ 35.1 3115 1926 02 5201 3115 1926 02 Diaphragm 1
35.11 3115 2617 10 5201 3115 2617 10 Plug 2
*& #35.12 9125 6191 00 5201 9125 6191 00 O-Ring 2
# 35.13 0661 1000 29 5201 0661 1000 29 Seal Washer 1
35.14 3176 6528 00 5201 3176 6528 00 Nipple 1
35.21 3115 2275 00 5201 3115 2275 00 Clamp 1
35.22 3115 2276 00 5201 3115 2276 00 Holder 1
35.23 0147 1328 03 5201 0147 1328 03 Screw, Hex Hend 2
35.24 0291 1128 19 5201 0291 1128 19 Lock Nut 2
101 3115 5042 00 5201 3115 5042 00 Front Part 1
$ 105 3115 5045 01 5201 3115 5045 01 Guide 1
# 106 3115 3024 00 5201 3115 3024 00 Wiper 1
110 3115 5044 05 5201 3115 5044 05 Flushing Head 1
# 111 3115 2333 00 5201 3115 2333 00 Cup Seal 2
# 112 3115 5190 00 5201 3115 5190 00 Cup Seal 1
* 115 3115 3289 17 5201 3115 3289 17 Seal Ring 3
118 3115 5059 00 5201 3115 5059 00 Washer 1
120 3115 5043 12 5201 3115 5043 12 Connect Plate 1
122 3115 1825 00 5201 3115 1825 00 Plug 1
# 124 3115 3445 00 5201 3115 3445 00 Seal Ring 1
@ 125 0147 1479 03 5201 0147 1479 03 Screws, Hex Head 2
@ 126 3315 0195 10 5201 3315 0195 10 Double Lock Washer 2
* 130 3115 3245 00 5201 3115 3245 00 Seal Ring 1
* 147 0663 2143 00 5201 0663 2143 00 O-Ring 1
141 3115 5340 10 5201 3115 5340 10 Retaining ring 1
* 146 0663 2145 01 5201 0663 2145 01 O-Ring 4
* 170 0663 6151 00 5201 0663 6151 00 O-Ring 2
* 180 3115 3245 00 5201 3115 3245 00 Seal Ring 1
@ 190 3115 5040 00 5201 3115 5040 00 Side Bolt 2
191 0102 0473 00 5201 0102 0473 00 Pin 1
152 3115 5036 10 5201 3115 5036 10 Cover 1
# 160 0666 7190 01 5201 0666 7190 01 Radial Lip Seal 1
@ 161 0335 2173 00 5201 0335 2173 00 Circlip 1
202 3115 5035 00 5201 3115 5035 00 Gear Housing 1
231 3115 0821 00 5201 3115 0821 00 Shaft 1
@ 232 0516 1504 01 5201 0516 1504 01 Needle Bearing 1
233 3115 0823 00 5201 3115 0823 00 Washer 1
234 3115 0274 00 5201 3115 0274 00 Gear Wheel 1
@ 235 0516 1538 00 5201 0516 1538 00 Needle Bearing 1
236 3115 0824 00 5201 3115 0824 00 Sleeve 1
# 237 0667 1206 00 5201 0667 1206 00 Seal 1
238 3115 2742 00 5201 3115 2742 00 Guide Sleeve 1
* 239 0663 2133 01 5201 0663 2133 01 O-Ring 1
@ 255 0509 0221 00 5201 0509 0221 00 Single row Tapered roller bearing 1
@ 256 0509 0223 00 5201 0509 0223 00 Tapered Roller Bearing 1
@ 257 3115 0297 01 5201 3115 0297 01 Shim 3
@ 258 3115 0297 02 5201 3115 0297 02 Shim 3
@ 259 3115 0297 03 5201 3115 0297 03 Shim 1
$ 260 3115 5314 00 5201 3115 5314 00 Driver 1
$ 261 3115 2968 01 5201 3115 2968 01 Rot. Ch. Bushing. 1
@ 265 3115 1457 00 5201 3115 1457 00 Side Bolt 1
* 270 3115 3245 00 5201 3115 3245 00 Seal Ring 2
* 271 0663 2120 00 5201 0663 2120 00 O-Ring 2
# 212 0544 2162 00 5201 0544 2162 00 Grease Nipple 1
# 214 0686 4201 03 5201 0686 4201 03 Plug 1
# 215 0653 9038 00 5201 0653 9038 00 Gasket 1
# 217 0666 7188 01 5201 0666 7188 01 Radial Lip Seal 1
@ 218 0335 2169 00 5201 0335 2169 00 Circlip 1
@ 221 3115 3613 00 5201 3115 3613 00 Stud 4
225 3115 0273 00 5201 3115 0273 00 Washer 1
204 0259 0311 00 5201 0259 0311 00 Thread Insert 4
251 3115 5313 80 20 5201 3115 5313 80 20 Rotation Chuck, Bare 1
252 3115 1881 00 5201 3115 1881 00 Bushing 1
340 3115 2384 00 5201 3115 2384 00 Valve seat 1
341 3115 2383 00 5201 3115 2383 00 Valve Cone 1
* 342 3115 3290 18 5201 3115 3290 18 Seal Ring 2
345 3115 3455 00 5201 3115 3455 00 Connect Plate 1
@ 346 0211 1960 84 5201 0211 1960 84 Screw 2
* 347 5750 5317 97 5201 5750 5317 97 O-Ring 4
* 350 3115 2988 00 5201 3115 2988 00 Seal Ring 3
* 352 3115 5146 01 5201 3115 5146 01 Seal Ring 1
356 3115 6009 79 5201 3115 6009 79 Seal Kit 1
$ 360 3115 2971 00 5201 3115 2971 00 Damping Piston 1
370 0686 9110 00 5201 0686 9110 00 Protection Plug 1
302 3115 5274 22 5201 3115 5274 22 Intermed.Part 1
320 3115 5358 02 5201 3115 5358 02 Liner 1
* 322 3115 3289 23 5201 3115 3289 23 Seal Ring 1
* 324 3115 3289 13 5201 3115 3289 13 Seal Ring 2
$ 326 3115 5360 00 5201 3115 5360 00 Disc Springs 1
328 3115 1746 06 5201 3115 1746 06 Nozzle 4
304 0259 2061 00 5201 0259 2061 00 Thread Insert 4
305 0259 0068 00 5201 0259 0068 00 Threaded Insert 2
306 3115 2401 00 5201 3115 2401 00 Plug 1
307 0686 6442 00 5201 0686 6442 00 Plug 1
# 308 0661 1020 00 5201 0661 1020 00 Seal Washer 1
401 3115 1944 00 5201 3115 1944 00 Cylinder 1
420 3115 5275 22 5201 3115 5275 22 Seal House 1
$ 425 3115 5050 01 5201 3115 5050 01 Piston Guide 1
$ 430 3115 3635 01 5201 3115 3635 01 Piston 1
$ 435 3115 1680 00 5201 3115 1680 00 Piston Guide 1
440 3115 2772 00 5201 3115 2772 00 Seal Housing 1
445 3115 1765 00 5201 3115 1765 00 Valve Piston 1
446 3115 2077 03 5201 3115 2077 03 Valve Cover 1
447 3115 2076 05 5201 3115 2076 05 Valve Cover 1
@450 0147 1438 03 5201 0147 1438 03 Screw, Hex Head 4
455 3115 3291 00 5201 3115 3291 00 Reg. Plug 1
456 3115 3214 00 5201 3115 3214 00 Nut 1
# 457 3115 1697 00 5201 3115 1697 00 Seal Washer 2
* 460 3115 3245 00 5201 3115 3245 00 Seal Ring 2
* 470 0663 6134 01 5201 0663 6134 01 O-Ring 1
* 471 0663 6134 01 5201 0663 6134 01 O-Ring 1
* 475 0663 2133 01 5201 0663 2133 01 O-Ring 1
* 476 0663 2133 01 5201 0663 2133 01 O-Ring 1
415 3115 1165 00 5201 3115 1165 00 Stud 4
416 3115 2112 00 5201 3115 2112 00 Guide 1
404 0259 0311 00 5201 0259 0311 00 Thread Insert 1
405 0259 0011 00 5201 0259 0011 00 Thread Insert 4
406 0259 2061 00 5201 0259 2061 00 Thread Insert 3
408 3115 1825 00 5201 3115 1825 00 Plug 1
409 0686 6447 04 5201 0686 6447 04 Plug 2
# & $ 410 0661 1034 00 5201 0661 1034 00 Seal Washer 2
# 422 3115 0970 00 5201 3115 0970 00 Seal Kit 2
* 423 0663 2105 76 5201 0663 2105 76 O-Ring 1
# 442 3115 1156 00 5201 3115 1156 00 Seal Kit 2
* 443 0663 6135 00 5201 0663 6135 00 O-Ring 1
501 3115 3481 00 5201 3115 3481 00 Back Hend 1
@505 0147 1481 03 5201 0147 1481 03 Screw, Hex Head 3
* 510 0663 6138 00 5201 0663 6138 00 O-Ring 1
* – 0663 2134 00 5201 0663 2134 00 O-Ring 1
* – 0663 2144 00 5201 0663 2144 00 O-Ring 1
* – 0663 6135 01 5201 0663 6135 01 O-Ring 2
* – 0663 6143 00 5201 0663 6143 00 O-Ring 1
* – 0663 6144 00 5201 0663 6144 00 O-Ring 1
0663 9104 01 5201 0663 9104 01 O-Ring 2
0663 9158 00 5201 0663 9158 00 O-Ring 1
0663 2100 53 5201 0663 2100 53 O-Ring 1
0663 2105 96 5201 0663 2105 96 O-Ring 1
0663 2109 36 5201 0663 2109 36 O-Ring 2
0663 2115 00 5201 0663 2115 00 O-Ring 1
0663 2133 00 5201 0663 2133 00 O-Ring 2
0663 6136 00 5201 0663 6136 00 O-Ring 1
* – 3115 2615 91 5201 3115 2615 91 Return Accum
* 3115 5042 80 5201 3115 5042 80
* – 3115 1603 91 5201 3115 1603 91 Nipple Set
* – 3115 5036 80 5201 3115 5036 80 Cover compl.
* – 3115 5035 81 5201 3115 5035 81 Gear housing,Assy
* – 3115 5313 80 5201 3115 5313 80 Rotation Chuck
* – 3115 5274 80 5201 3115 5274 80 Interm Compl.
* – 3115 1944 80 5201 3115 1944 80 Cylinder
* – 3115 5275 80 5201 3115 5275 80 SEAL HOUSE COMP
* – 3115 2772 80 5201 3115 2772 80 Seal House Comp
* – 3115 9170 90 5201 3115 9170 90 O-Ring Kit
* – 3115 9170 91 5201 3115 9170 91 Seal Kit
* – 3115 9238 93 5201 3115 9238 93 Repair Kit, 600Hrs
* – 3115 9238 94 5201 3115 9238 94 Repair Kit 1200Hrs
